high quality Barco SLite 10XP LED tiles

Visual Resolution: 10mm, high bright LED display

Brightness: 6500 NIT

LED configuration: 2R, 1G, 1B

Viewing Angle: (Hor. 120°, Vert. 60°) Optimal viewing conditions are guaranteed for all viewers. Irrespective of which direction the sunshine falls on the screen or where viewers sit within an arena, they are all ensured of the best quality image.

Contrast ratio: 2000:1 at 200 lux

Ruggedness: IP 65 certification, each module is dust and weather proof allowing the screen to be used in harsh outdoor environments.

Hot Swapping: In most cases the SLite panels can be serviced while the rest of the wall is still operational. This feature guarantees continuous performance.

Input Compatibility: SDI, RGBHV / RGBS / RGsB computer video, Component video (std or HDTV), S-video, or Composite Video

Rugged Replaceable Shaders: Shaders are made from a new impact proof, two-component material making them much more rugged and less prone to breakage. Should damage occur, then shaders can now be easily replaced in the field.

Content: Showscreens can provide content for display on video screens, some examples are 3D graphics or live broadcast quality camera feeds.

Processing: 14 bit processing combined with XP (LED level) calibration, results in even greater color depth and uniformity, allowing the display to show vibrant images with even deeper and more uniform colors across the entire surface of the display.

Colors: 4.4 trillion

Refresh rate: > 2000 Hz (PAL / NTSC), much more stable and there is no loss of visual information when using the camera for broadcasting.

Production: Modular design allowing almost any shape and size to be built. Can be stacked off the floor or hung from a structure above. This allows for our screens to be used in most indoor and outdoor locations.

Shader Design: incorporates a new revolutionary “light trap” shader. Its radically new geometric design combined with specially selected dark black, matt materials essentially “traps” the light falling on the display ensuring superb black levels. When combined with the high brightness output level of 5,500 NIT (calibrated), the SLite 10 XP now delivers vastly improved contrast levels compared to other products.

Ultra high brightness: The SLite 10 XP delivers a brightness of 6500 NIT (5500 NIT calibrated). This results in the perfect solution for all outdoor LED applications.
